Keep Your Knee Moving. Speed Up Your Recovery.
The CPM-B Knee Rehabilitation Machine delivers continuous passive motion (CPM) therapy — gently moving the knee through controlled flexion and extension cycles to restore joint mobility after surgery, injury or stroke.
For broader continuous passive motion coverage, see the ZB-X1002E CPM Knee Machine, the Upper-Limb CPM 2-in-1 and the YTK-E Upper-Limb CPM in our CPM equipment range.
The Challenge
After knee surgery, fracture, stroke or arthritis, the joint stiffens when it doesn’t move. Stiffness, swelling, limited range of motion and fear of pain slow down recovery — and patients can’t always access enough manual physiotherapy to make steady progress.
The CPM-B Solution
The CPM-B automatically moves the leg through smooth, repeatable flexion and extension cycles without requiring patient effort. This continuous passive motion promotes joint healing, reduces stiffness and swelling, and progressively restores the knee’s range of motion — whether in the hospital, rehab center, or at home. Patients simply relax while the machine does the work, making therapy consistent, pain-free and easy to repeat day after day.
Who It’s For
Post-operative patients — after knee replacement, ligament repair, fracture fixation and other lower limb surgeries
Stroke and hemiplegia patients — recovering leg movement and joint flexibility
Arthritis patients — managing joint stiffness and maintaining mobility
Injury recovery — ankle sprain, sprain, foot drop and other lower limb conditions
Care settings — hospital, rehab center, household care center and home use
Key Features
Wide Training Angle Range — adjustable from -5° to 120° for progressive, stage-by-stage range-of-motion recovery.
Automatic Passive Training — the machine drives continuous flexion and extension cycles with no patient effort required, ideal for post-op, stroke and elderly patients.
Stainless Steel, Built to Last — durable steel frame designed for long-term daily use in both clinical and home environments.
Portable & Space-Saving — compact footprint with easy transport between hospital and home care settings.
Universal Power Compatibility — works with 100-240V, 50/60Hz power; choose from EU, US, UK or AU plug options.
Simple, One-Step Operation — designed for easy use by patients and caregivers alike, with minimal setup.
Certified Quality — MDR CE approved and FDA compliant, classified as a Class II medical device.
| Parameter | Specification |
|---|---|
| Knee joint motion angle | -5° to 120° |
| Hip joint motion angle | 25° to 100° |
| Ankle joint motion angle | 20° extension to 45° flexion |
| Femur alignment range | 32 to 49 cm |
| Tibia alignment range | 25 to 57 cm |
| User height suitability | 110 to 195 cm |
| Limb load capacity | Up to 20 kg |
| Working noise | ≤ 60 dB |
| Main voltage | 100-240 V, 50 Hz |
| Control modes | Normal / angle progression (+3° per 15 min) / speed progression (up to 9 levels) |
| Safety | Emergency stop switch + patient hand control |
Customized logo and packaging accepted — we support OEM/ODM production to match your brand positioning.
Give your patients the gift of pain-free, consistent knee recovery — anywhere, anytime.
Contact us today for quotation, samples and technical support.
